SAMSUNG 46inch LSC460HQ03-W LCD Panel

Product Categories
Mega Source Elec.Limited
Contact Now

SAMSUNG 46inch LSC460HQ03-W LCD Panel

Place of Origin : Japan

Brand Name : SAMSUNG

Certification : RoHS Compliant

Model Number : LSC460HQ03-W

MOQ : 1 PCS

Price : Pls Contact sales team

Packaging Details : MODULE

Delivery Time : stock

Payment Terms : T/T , Paypal, Western Union Escrow etc.

Supply Ability : 1000

Panel Model : LSC460HQ03-W

Panel Brand : SAMSUNG

Descrition : a-Si TFT-LCD ,46 inch, 1920×1080

Panel Type : a-Si TFT-LCD

Contact Now

SAMSUNG 46inch LSC460HQ03-W LCD Panel

Specification for LSC460HQ03-W:

Panel Model

LSC460HQ03-W

Panel Brand

SAMSUNG

Descrition

a-Si TFT-LCD ,46 inch, 1920×1080

Panel Type

a-Si TFT-LCD

Display Mode

SVA, Normally Black, Transmissive

Active Area

1018.08×572.67 mm

Outline

1025.98×580.57 mm

Surface

Glare (Haze 0%)

Contrast Ratio

5000:1 (Typ.)

Display Colors

1.07B (8-bit + Dithering) , CIE1931 69%

Response Time

4 (Typ.)(G to G)

Viewing Angle

89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)

Frequency

120Hz (60Hz Input)

Signal Interface

LVDS (4 ch, 8/10-bit) , 92 pins

Input Voltage

12.0V (Typ.)
