INNOLUX 5inch 5DW FOG LCD Panel

Place of Origin : Japan

Brand Name : INNOLUX

Certification : RoHS Compliant

Model Number : 5DW FOG

MOQ : 1 PCS

Price : Pls Contact sales team

Packaging Details : MODULE

Delivery Time : stock

Payment Terms : T/T , Paypal, Western Union Escrow etc.

Supply Ability : 1000

Panel Model : 5DW FOG

Panel Brand : INNOLUX

Descrition : a-Si TFT-LCD ,5.0 inch, 480×272

Panel Type : a-Si TFT-LCD

Contact Now

INNOLUX 5inch 5DW FOG LCD Panel

Specification for 5DW FOG:

5DW FOG Basic Information

Panel Model

5DW FOG

Panel Brand

INNOLUX

Descrition

a-Si TFT-LCD ,5.0 inch, 480×272

Panel Type

a-Si TFT-LCD

Operating Temperature

-20 ~ 70 °C

Storage Temperature

-30 ~ 80 °C

5DW FOG Mechanical Features

Dot Resolution

480(RGB)×272 (WQVGA)

Pixel Configuration

RGB Vertical Stripe

Pixel Density

109 PPI

Aspect Ratio

16:9 (H:V)

Form Factor

Flat Rectangle Display

Dot Pitch

0.077×0.231 mm (H×V)

Pixel Pitch

0.231×0.231 mm (H×V)

Weight

TBD

Surface

Antiglare

Active Area

110.88×62.832 mm (H×V)

Outline Dimension

117.7×72.8 mm (H×V)

Outline Depth

1.43 (Typ.) mm

Landscape or Portrait

Landscape type

Touch Panel

Without

5DW FOG Optical Features

Display Mode

TN, Normally White, Transmissive

Brightness

0 cd/m²

Contrast Ratio

500 : 1 (Typ.) (Transmissive)

Display Color

16.7M (8-bit)

Response Time

10/15 (Typ.)(Tr/Td)

Viewing Angle

70/70/50/70 (Typ.)(CR≥10) (L/R/U/D)

Viewing Direction

6 o'clock

Sunlight Readable

N

5DW FOG Electronics Feature

Reverse Scan

No

5DW FOG Backlight System

Lamp Type

No B/L

5DW FOG Signal Interface

Signal Category

TTL

Signal Class

Parallel RGB (1 ch, 8-bit)

Input Voltage for Panel

3.3V (Typ.)

Input Current for Panel

19/25mA (Typ./Max.)

Panel Power Consumption

63mW (Typ.)

Voltage for Display Signals

0≤VIL≤0.2VDD; 0.8VDD≤VIH≤VDD

Interface Type

FPC
