TPO 2.5inch TE025THZB4 LCD Panel

Place of Origin : Japan

Brand Name : TPO

Certification : RoHS Compliant

Model Number : TE025THZB4

MOQ : 1 PCS

Price : Pls Contact sales team

Packaging Details : MODULE

Delivery Time : stock

Payment Terms : T/T , Paypal, Western Union Escrow etc.

Supply Ability : 1000

Panel Model : TE025THZB4

Panel Brand : TPO

Descrition : LTPS TFT-LCD ,2.5 inch, 640×240

Panel Type : LTPS TFT-LCD

Contact Now

TPO 2.5inch TE025THZB4 LCD Panel

Specification for TE025THZB4:

TE025THZB4 Basic Information

Panel Model

TE025THZB4

Panel Brand

TPO

Descrition

LTPS TFT-LCD ,2.5 inch, 640×240

Panel Type

LTPS TFT-LCD

Operating Temperature

-10 ~ 60 °C

Storage Temperature

-30 ~ 80 °C

TE025THZB4 Mechanical Features

Dot Resolution

640×240 (HVGA)

Pixel Configuration

RGB Delta

Pixel Density

129 PPI

Aspect Ratio

4:3 (H:V)

Form Factor

Flat Rectangle Display

Dot Pitch

0.0786×0.1575 mm (H×V)

Weight

7.1g

Surface

Hard coating (3H)

Active Area

50.279×37.8 mm (H×V)

Outline Dimension

57.78×41.9 mm (H×V)

Outline Depth

1.26 (Typ.) mm

Landscape or Portrait

Landscape type

Touch Panel

Without

TE025THZB4 Optical Features

Display Mode

TN, Normally White, Transmissive

Brightness

0 cd/m²

Contrast Ratio

300 : 1 (Typ.) (Transmissive)

Display Color

16.7M (8-bit)

Response Time

13/22 (Typ.)(Tr/Td)

Viewing Angle

40/40/20/50 (Typ.)(CR≥10) (L/R/U/D)

White color Chromaticity

Wx:0.310; Wy:0.330

Transmissivity

10.5% (Typ.)(with Polarizer)

Sunlight Readable

N

TE025THZB4 Electronics Feature

Vertical Frequency

60Hz

Reverse Scan

No

TE025THZB4 Backlight System

Lamp Type

No B/L

Interface Type

Included in panel signal interface

Lamp Driver Board

No

TE025THZB4 Signal Interface

Signal Category

Serial RGB

Signal Class

Serial RGB (8-bit) + SPI

Input Voltage for Panel

3.0V (Typ.)

Panel Power Consumption

50/60mW (Typ./Max.)

Voltage for Display Signals

0≤VIL≤0.2VCC; 0.8VCC≤VIH≤VCC

Interface Type

FPC

Below is some of our other LCD panel hot offer,pls check if you need any of them:

AT056TN52 V.5

INNOLUX

5.6"

640×480

TX09D80VM3CCA

KOE

3.5"

240×320

LQ038Q7DB03

SHARP

3.8"

240×320

LQ065T9BR53U

SHARP

6.5"

400×240

TM035WDH01-00

TIANMA

3.5"

480×640

ET035A6448-1

3.5"

480×640

COM41T4M28XLC

4.1"

320×240

NL2432HC22-45A

NLT

3.5"

240×320

L5S30878P01

Epson

3.0"

240×400

TFT-GG1P0553UTSW-W-E

1.7"

176×220

TD043MTEA1

TPO

4.3"

800×480

TX09D80VM3CEA

KOE

3.5"

240×320

TS047NAARB02-00

TIANMA

4.7"

480×272

LTE430WQ-F0C

SAMSUNG

4.3"

480×272

TM047NDH01

TIANMA

4.7"

480×272

LQ043T1DG28

SHARP

4.3"

480×272

DT24032035-41

3.5"

240×320

LQ065T5DG04

SHARP

6.5"

480×234

LB070WV1-TD04

LG Display

7.0"

800×480

LQ079L1SX01

SHARP

7.9"

1536×2048

LS013B7DH01

SHARP

1.26"

144×168

A035VL01 V3

AUO

3.5"

800×480

A035VL01 V2

AUO

3.5"

800×480

A035VL01 V1

AUO

3.5"

800×480

A035VL01 V0

AUO

3.5"

800×480

A035VW01 V0

AUO

3.5"

800×480

LQ065T9BR55U

SHARP

6.5"

400×240

AMS309PW01-0

SAMSUNG

3.1"

720×720

COM50T5124GTC

5.0"

320×240

TX09D70VM1CBC

KOE

3.5"

240×320

AMS353FD09-0

SAMSUNG

3.5"

480×800

LQ088H9DR01

SHARP

8.8"

640×240

TD028TTEC1

TPO

2.8"

480×640

LS030Y3DX01

SHARP

3.0"

480×800

LQ035Q7DB06

SHARP

3.5"

240×320

Product Tags:

High sensitive delay



Time delay relay


Wholesale TPO 2.5inch TE025THZB4 LCD Panel from china suppliers

TPO 2.5inch TE025THZB4 LCD Panel Images
